10. DOUBLE-FEED DETECTION SECTION
10-1. Adjusting the Light-emitting Volume in Use of Thick Paper and Thin Paper
(Maintenance Menu)
To adjust the light-emitting volume of the LED when using thin paper: Adjust so that the light-receiving value is 155 on
average for 52.3 g/m
2
paper.
To adjust the light-emitting volume of the LED when using thick paper: Adjust so that the light-receiving value is 155
on average for 127.9 g/m
2
paper.
