Duplo DSF-2000 - Structure of Conveyance Rollers and Conveyance Guides

1-28 99T-M12M0-0107-0
12. STRUCTURE OF CONVEYANCE ROLLERS AND CONVEYANCE GUIDES
Conveyance rollers and conveyance guides are arranged as shown in the figure below.
∗ Refer to Grease the following parts in “14. MAINTENANCE”
Conveyance
rollers
Conveyance roller
Paper feed
conveyance roller
Reversal roller 1
Reversal roller 2
Secondary rollers
Secondary roller
Secondary conveyance rollers
∗
Paper feed conveyance roller
Suction belt
Paper feed section
secondary conveyance roller
∗
Paper feed section
secondary conveyance roller
∗
Bridge rollers
Suction belt
