1-2
99T-M12M0-0107-0
1. OUTLINE OF MECHANISM OF THIS MACHINE
1-1. Operations of Machine during Count Processing Mode and When Using End
Mark (Count Mode)
(1) Perform the required settings for count processing or using the end mark on the control panel.
(2) Memorize the characteristics of the paper in the machine by test feeding the paper.
(3) Press the start button to start operations.
(4) The number of sheets for one set is fed from the paper feeder A and sent to the downstream processing unit.
(At this time, it is possible to use the reversal mechanism to turn paper inside out when sending it to the
downstream processing unit.)
(5) When using the end mark, the machine will check that the last sheet of paper in the set from the paper feeder A
has an end mark on it. If no end mark, the machine will stop.
(6) Cover paper is fed from the paper feeder B, and the execute processing signal is sent to the downstream
processing unit.
(7) The paper for the next set is fed from the paper feeder A after the time required by the downstream processing
unit to perform operations.
(8) When the number of sets set has been processed, the machine will stop.
1-2. Operations of Machine during Random Processing Mode
(1) Perform the required settings for random processing on the control panel.
(2) Memorize the characteristics of the paper with the end mark in the machine by test feeding the paper.
(3) Press the start button to start operations.
(4) Paper is fed from the paper feeder A and sent to the downstream processing unit.
(5) When paper with the end mark is fed, cover paper will be fed from the paper feeder B, and the execute processing
signal will be sent to the downstream processing unit.
(6) The paper for the next set is fed from the paper feeder A after the time required by the downstream processing
unit to perform operations.
(7) The machine will stop when the paper feed tray A or B runs out of paper.
