1-24
99T-M12M0-0107-0
9-3. Adjusting the Light-emitting Volume of the End Mark Sensor
(Maintenance Menu)
If the end mark sensor or MC unit has been replaced, the light-emitting volume must be adjusted in the maintenance
menu.
Place a 52.3 g/m
2
paper in the conveyance route of the end mark sensor detection section, and adjust the light-
emitting volume (LED setting value) so that both the PD1 and PD2 values are between 110 and 120.
9-4. Cleaning
Remove paper bits, etc. by blowing air during periodic maintenance.
To Next Page
