13 | Technical data
146
D-ISC 100 x xx2
13 Technical data
13.1 Technical data D-ISC 100
Inputs/outputs, D‑ISC100 TypeC TypeM TypeP TypeR
Analogue outputs
4…20mA, 400Ohm, potential-free,
assignment parametrisable
1 1 1 1
with expansion modules (option) - up to 17 up to 9 up to 17
Analogue inputs
with expansion modules (option)
- up to 16 up to 8 up to 16
Digital outputs
Contact NC/NO, max. load
60VDC/30VAC/0.5A potential-free,
function parametrisable;
typically: Maintenance, failure
2 2 2 2
with expansion modules (option) - up to 34 up to 18 up to 34
Digital inputs
with expansion modules (option)
- up to 32 up to 16 up to 32
Table13.1: Inputs/outputs
Digital interfaces on the D‑ISC100 TypeC TypeM TypeP TypeR
USB (service) 1
(inside the housing)
1 1
(inside the housing)
1
DURAG Modbus 1 1 1 1
Modbus RTU / RS485 (option) 1 1 1 1
Profibus DP (option) - 1 1 1
Modbus TCP (option) 1 1 1 1
Table13.2: Digital interfaces
Technical data for the D‑ISC100 TypeC TypeM TypeP TypeR
Operating voltage 90 - 264 V~, 48 - 62 Hz
Power consumption 200VA 200VA 450VA 200VA
IP protection class (EN60529) IP65 IP65
(apart from
purge air inlet)
IP20
Permissible ambient temperature
(operation)
-20…+50°C, -40…+60°C (option) -20...+50°C
(storage) -40...60°C
Relative humidity 0…95% RF, non-condensing
Altitude <2000m
Overvoltage category CAT II
Electrical connections
Device connection via:
DURAG standard plug M23
1 1 1 -
Panel jack M23 (option) 1 1 - -
