Menu functions
ITEM SETTINGS EXPLANATION
HUB LINK SETTING AUTO NEGOTIATE
100BASE-TX FULL
100BASE-TX HALF
10BASE-T FULL
10BASE-T HALF
Sets full or half duplex for communication via a
network hub.
When AUTO is set, negotiation is done
automatically.
NETWORK SCALE NORMAL / SMALL Selects network size.
When NORMAL is selected, printer can work
effectively, even when connected to a HUB that
has a spanning tree feature. However, printer
start up time gets longer when computers are
connected with two or three small LANs.
When SMALL is selected, computers can cover
from two or three small LANs to a large LAN, but
may not work effectively when connected to a
HUB that has a spanning tree feature.
SNMP ENABLE / DISABLE Enables or disables SNMP protocol.
IPSEC ENABLE / DISABLE Sets Enable/Disable of IPSec. Enable via the
web.
Enable: IPSec is available.
Disable: IPSec is not available.
FTP ENABLE / DISABLE Enables or disables communication via FTP.
TELNET ENABLE / DISABLE Enables or disables Telnet config. facility.
WEB ENABLE / DISABLE Enables or disables Web config. facility.
GATEWAY ADDRESS xxx.xxx.xxx.xxx Current assigned gateway address. To change,
proceed as above.
SUBNET MASK xxx.xxx.xxx.xxx Current assigned subnet mask. To change,
proceed as above.
IPV4 ADDRESS xxx.xxx.xxx.xxx Current assigned IP address. To change, press
OK and use Menu buttons to increment 1st
octet, then press OK again to move on to next
octet. When 4th octet has been set, press OK
again to register new address.
IP ADDRESS SET AUTO / MANUAL Specifies whether IP address allocation is
automatic (DHCP) or manually assigned.
ETHERTALK ENABLE / DISABLE Enables or disables this network protocol.
NETWARE ENABLE / DISABLE Enables or disables this network protocol.
NETBIOS OVER TCP ENABLE / DISABLE Sets Enable/Disable of NetBIOS over TCP
protocol.
Display Conditions:
> TCP/IP should be enabled.
> IP Version is not IPv6.
NETBEUI ENABLE / DISABLE Enables or disables this network protocol.
NETWORK MENU (continued)
