Menu functions
ITEM SETTINGS EXPLANATION
C HIGHLIGHT
C MID-TONE
C DARK
M HIGHLIGHT
M MID-TONE
M DARK
Y HIGHLIGHT
Y MID-TONE
Y DARK
K HIGHLIGHT
K MID-TONE
K DARK
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
-3~0~+3
Adjusts image density for each color component (cyan,
magenta, yellow and black). Normal setting is 0.
COLOR TUNING PRINT PATTERN Selecting this item prints the color tuning pattern to help
you adjust the color balance.
ADJUST DENSITY EXECUTE Selecting this will activate adjustment of the color density.
MEDIA MENU
This menu provides adjustment to suit a wide range of print media.
ITEM SETTINGS EXPLANATION
TRAY1 PAPERSIZE A4 /A5/ A6/B5/LEGAL14/
LEGAL13.5/LEGAL13/
LETTER/EXECUTIVE
16K(184x260mm)
16K(195x270mm)
16K(197x273mm)
CUSTOM
HAGAKI
Selects the size of paper loaded in Tray 1 (upper
tray if both trays installed). For CUSTOM setting
see XDIMENSION and Y-DIMENSION in “Print
menu” in "10.4 Menus" section.
UNIT OF MEASURE INCH
MILLIMETER
Selects the unit of measure.
Note: The default setting varies depending on the
sales area.
MPT MEDIAWEIGHT LIGHT
MEDIUM LIGHT
MEDIUM
HEAVY
ULTRA HEAVY1
ULTRA HEAVY2
Selects the media weight to be fed from the multi-
purpose tray.
COLOR MENU (continued)
