Fine adjustment (right end position)
–
For a 17 mm cutting block, set a buttonhole of 16 mm length
without tack and for a 10 mm cutting block, set a buttonhole
of 9 mm length without tack on the control panel.
–
Insert a tapping needle (short needle).
–
Insert a piece of cardboard as sewing material.
–
Sew a buttonhole.
–
Measure the cutting length.
The cutting length must amount exactly either 16 mm or 9 mm.
Correction
–
Loosen screw 2.
–
Adjust the right end position of the cutting block by means of the
screw 1.
Turn the screw to the right = increase the cutting length
Turn the screw to the left = decrease the cutting length
–
Tighten screw 2.
41
3
21
