Programming
154 Operating Instructions 745-35-10 S/745-35-10 A - 03.0 - 04/2017
Testing the light barriers
The display switches to Align light barriers.
Fig. 127: Test the light barriers
Information
Depending on the light barrier configuration, the system will display 1 or 2
light barriers ( p. 143).
Refer to the Service Instructions for instructions on how to align the
light barriers with the help of templates.
To align the light barriers:
1. Press the button.
Reference run is carried out.
CAUTION
Risk of injury from moving parts!
Crushing possible.
Do NOT reach into the moving part of the machine.
