Operation
Operating Instructions 745-35-10 S/745-35-10 A - 03.0 - 04/2017 39
Position of the adjustable knife block (745-35-10 S only)
Fig. 29: Position of the adjustable knife block (745-35-10 S only)
The position of the adjustable knife block corresponds to the seam length
that has been set in the global parameters.
To set the position of the adjustable knife block:
1. Loosen the clamping lever (6).
2. Set seam length L1 on scale (5).
Tighten the clamping lever (6) again.
4.16 Setting the reference position
The reference position is necessary in order to obtain a defined initial
position.
To set the reference position:
1. Switch on the main switch.
 The control is initialized.
 The control checks whether the transport carriage is at its rear end
position. If not, the display shows the message Reference run:
Info 9000 .
2. Press the pedal back.
 The reference run starts. The transport carriage moves to its rear end
position.
(5) - Scale (6) - Clamping lever
⑤⑥
