Setup
214 Operating Instructions 745-35-10 S/745-35-10 A - 03.0 - 04/2017
7.2.5 Setting the working height
The working height can be adjusted between 797 mm and 1138 mm (mea-
sured to the upper edge of the tabletop).
The sewing unit has been set to the lowest working height of 797 mm at
the factory.
Fig. 182: Setting the working height
To set the desired working height:
1. Loosen the screws (1).
2. Set the tabletop to the desired working height.
3. To avoid jamming, slide the stand pipes in or out evenly at both sides.
4. Tighten the screws (1).
WARNING
Risk of injury due to unstable footing!
Tipping of the sewing unit.
Use caution when loosening the screws.
(1) - Screws
