- 101 -
Thrust Washer (for 600H)
WT163015
6
8. Parts List & Illustrations
8.4 Arch Group (continued)
Description
Part Number
Qty
Thrust Washer (for 800H/1000H)
WT163015
8
35
Bearing, CF8
BRCF8
1
36
Bearing, Nast6 (for 850W~1650W)
BRNAST6
1
38
Metal Bushing, 0806
MB0806
6
41
Key, 5x5x10
KYA050510
1
47
HBS, M5x16 (N)
HBS0516N
2
HBS, M5x16 (Stainless Steel)
HBS0516S
2
49
HBS, M6x16 (N) (for 400H~800H)
HBS0616N
2
50
HBS, M6x20 (N)
HBS0620N
1
51
HBS, M6x30 (N)
HBS0630N
5
52
HBS, M8x30 (N)
HBS0830N
2
56
THS, M6x12 (N) (1000H only)
THS0612N
2
THS, M6x12 (Stainless) (1000H only)
THS0612S
2
57
THS, M6x25 (N) (850W~1650W)
THS0625N
1
58
THS, M6x30 (N) (for 400H/500H)
THS0630N
4
THS, M6x30 (N) (for 600H)
THS0630N
6
THS, M6x30 (N) (for 800H/1000H)
THS0630N
8
THS, M6x30 (Stainless) (400H/500H)
THS0630S
4
THS, M6x30 (Stainless) (600H)
THS0630S
6
THS, M6x30 (Stainless) (800H/1000H)
THS0630S
8
61
HN, M6 (for 400H/500H)
HN06
14
HN, M6 (for 600H)
HN06
16
HN, M6 (for 800H/1000H)
HN06
18
62
HSS, M5x6 (G)(N)
HSS0506GN
2
63
HSS, M6x8 (G)(N)
HSS0608GN
1
66
SW, M5
SW05
2
SW, M5 (Stainless Steel)
SW05S
2
67
SW, M6
SW06
17~21
68
SW, M8
SW08
3
72
PW, M6 (A) (for 550W/650W)
PW06A
19
PW, M6 (A) (for 850W~1650W)
PW06A
21
