Eagle 710 - 8. Parts List & Illustrations; 8.4 Arch Cover Group (continued)

- 114 -
8. Parts List & Illustrations
8.4 Arch Cover Group (continued)
Description
Part Number
Qty
Arch Cover Group
M7-2-300001
1
Arch Cover Group (Stainless)
M7-2-300001S
1
1
Arch Cover RH (for 400H)
M7-2-301101
1
Arch Cover RH (Stainless) (400H)
M7-2-301101S
1
Arch Cover RH (for 500H)
M7-2-301111
1
Arch Cover RH (Stainless) (500H)
M7-2-301111S
1
Arch Cover RH (for 600H)
M7-2-301121
1
Arch Cover RH (Stainless) (600H)
M7-2-301121S
1
Arch Cover RH (800H)
M7-2-301131
1
Arch Cover RH (Stainless) (800H)
M7-2-301131S
1
Arch Cover RH (1000H)
M7-2-301141
1
Arch Cover RH (Stainless) (1000H)
M7-2-301141S
1
2
Foam Rubber
FR-12006300
1
3
Foam Rubber
FR-12006301
1
4
Block Ass’y (for 550W~1050W)
M7-2-310000
1
5
Grommet
T5-4-10580
1
6
Guide LH (550W)
M7-2-101100
1
Guide LH (Stainless) (550W)
M7-2-101100S
1
Guide LH (650W)
M7-2-101110
1
Guide LH (Stainless) (650W)
M7-2-101110S
1
Guide LH (850W)
M7-2-101120
1
Guide LH (Stainless) (850W)
M7-2-101120S
1
Guide LH (1050W)
M7-2-101130
1
Guide LH (Stainless) (1050W)
M7-2-101130S
1
Guide LH (1250W)
M7-2-101140
1
Guide LH (Stainless) (1250W)
M7-2-101140S
1
Guide LH (1650W)
M7-2-101150
1
Guide LH (Stainless) (1650W)
M7-2-101150S
1
7
Guide RH (550W)
M7-2-101200
1
Guide RH (Stainless) (550W)
M7-2-101200S
1
Guide RH (650W~1050W)
M7-2-101210
1
Guide RH (Stainless) (650W~1050W)
M7-2-101210S
1
Guide RH (1250W/1650W)
M7-2-101230
1
Guide RH (Stainless) (1250W/1650W)
M7-2-101230S
1
8
Cover
M7-2-301800
1
Cover (Stainless)
M7-2-301800S
1
9
Proximity Sensor (X19)(SQ6)
MV-6-20220
1
10
Support Rod (1250W/1650W)
T7-2-20470
2
11
Arch Cover LH (400H)
M7-2-301400
1
Arch Cover LH (Stainless) (400H)
M7-2-301400S
1
Arch Cover LH (500H)
M7-2-301410
1
