Eagle 710 - 8. Parts List & Illustrations; 8.4 Tension Group (continued)

- 89 -
8. Parts List & Illustrations
8.4 Tension Group (continued)
Description
Part Number
Qty
Tension Group (for 5-6mm)
M7-1-400002
1
Tension Group (for 9mm)
M7-1-400012
1
1
Tension Guide Wheel (for 5-6mm)
M7-1-401100
1
Tension Guide Wheel (Stainless Steel)
(for 5-6mm)
M7-1-401100S
1
Tension Guide Wheel (for 9mm)
M7-1-401110
1
Tension Guide Wheel (Stainless Steel)
(for 9mm)
M7-1-401110S
1
2
Guide (for 5-6mm)
M7-1-401200
1
Guide (for 9mm)
M7-1-401210
1
3
Tension Guide (for 5-6mm)
M7-1-401301
1
Tension Guide (for 9mm)
M7-1-401311
1
4
Shaft
M7-1-401400
1
5
Bracket
M7-1-401500
1
6
Gear
M7-1-401600
1
9
M3 Motor
M7-1-301100
1
M3 Motor (for 9mm, 45kg tension)
M7-1-301110
1
11
Tension Crank Assembly (for 5-6mm)
M7-1-410001
1
Tension Crank Assembly (for 9mm)
M7-1-410011
1
12
Tension Arm Assembly
M7-1-420001
1
Tension Arm Assembly
(for 9mm, 45kg tension)
M7-1-420011
1
16
Washer
TB-223
1
17
Washer
AD-2-20181
2
21
Key, 5x5x27
KYA050527
1
23
HBS, M4x12 (N)
HBS0412N
4
25
HBS, M5x16 (N)
HBS0516N
5
28
HBS, M6x40 (H)(N)
HBS0640HN
1
29
HBS, M6x55 (H)(N)
HBS0655HN
1
31
HB, M6x12
HB0612
1
32
HSS, M5x6 (G)(N)
HSS0506GN
2
34
SW, M4
SW04
4
35
SW, M5
SW05
5
36
SW, M6
SW06
3
40
PW, M6 (C)
PW06C
1
