Eagle 710 - 8. Parts List & Illustrations; 8.4 Auto Strap Ejecting Assembly (continued)

- 160 -
8. Parts List & Illustrations
8.4 Auto Strap Ejecting Assembly (continued)
Description
Part Number
Qty
Auto Strap Ejecting Ass’y (for 5-6mm)
M7-3-310003
1
Auto Strap Ejecting Ass’y (for 9mm)
M7-3-310012
1
1
Sensor Bracket
M7-3-312700
1
2
Inlet Guide (for 5-6mm)
M7-3-312800
1
Inlet Guide (for 9mm)
M7-3-312810
1
3
Cover
M7-3-312900
1
4
Spring Hook
M7-3-313000
1
5
Roller
M7-3-313100
1
6
Cover Protect
M7-3-313400
1
11
Roller Assembly
M7-3-210001
1
14
Roller
M7-3-211200
1
15
Collar
M7-3-211300
1
16
Sensor Lever Support
M7-3-241300
2
17
Sensor Lever
M7-3-241401
1
18
Shaft
M7-3-241500
1
19
Shaft
M7-3-241600
1
20
Spring
M7-3-313200
1
22
Proximity Sensor (X18)(SQ5)
MV-6-20220
1
23
Washer
H44-10950
2
26
Bearing, 686ZZ
BR686ZZ
2
31
Snap Ring, E-3
ER03
3
32
Snap Ring, E-4
ER04
2
34
HBS, M4x8 (N)
HBS0408N
1
35
HBS, M3x6 (N)
HBS0306N
2
36
HBS, M5x12 (N)
HBS0512N
2
37
HBS, M5x20 (N)
HBS0520N
2
38
HBS, M6x35 (N)
HBS0635N
1
41
PMS, M3x16
PMS0316
2
43
TMS, M4x8 (N)
TMS0408N
2
44
TMS, M4x10 (N)
TMS0410N
2
51
SW, M3
SW03
2
53
SW, M5
SW05
2
52
SW, M4
SW04
1
56
PW, M5
PW05
2
61
HN, M6
HN06
1
