8. Parts List & Illustrations
8.4 Tension Arm Assembly (continued)
Description
Part Number
Qty
Tension Arm Assembly
M7-1-420001
1
Tension Arm Assembly
(for 9mm, 45kg tension)
M7-1-420011
1
1
Tension Arm
M7-1-421101
1
2
Shaft
M7-1-421200
1
4
Spring Support
M7-1-421400
1
5
Spring
M7-1-421510
1
Spring (for 9mm, 45kg tension)
M7-1-421520
1
6
Nut
M7-1-421600
1
7
Collar
M7-1-421700
1
8
Connecting Rod (Upper)
M7-1-421800
1
9
Connecting Rod (Lower)
M7-1-421900
1
10
Connecting Rod Set
M7-1-420100
1
11
Washer
TB-223
1
16
Bearing, CF8
BRCF8
1
17
Bearing, 6902ZZ
BR6902ZZ
2
18
HB,M6x12
HB0612
1
21
FLG, M6
FLG06
1
24
SW, M6
SW06
1
25
SW, M8
SW08
1
31
HN, M8
HN08
1
