Eagle 710 - 8. Parts List & Illustrations; 8.4 Outer Flange Assembly (continued)

- 167 -
8. Parts List & Illustrations
8.4 Outer Flange Assembly (continued)
Description
Part Number
Qty
Outer Flange Ass’y (for 200mm)
M7-4-110001
1
Outer Flange Ass’y (for 150mm)
M7-4-110010
1
1
Outer Flange (for 200mm)
M7-4-111101
1
Outer Flange (for 150mm)
T7-4-10122
1
2
Plate (for 150mm)
M7-4-111200
1
3
Spring (for 200mm)
M7-4-111310
1
Spring (for 150mm)
M7-4-111300
1
6
Label
LA-30240
1
11
HBS, M4x16 (N) (for 150mm)
HBS0416N
4
12
HBS, M5x12 (N) (for 200mm)
HBS0512N
4
HBS, M6x10 (N) (for 150mm)
HBS0610N
4
16
SW, M4 (for 150mm)
SW04
4
17
SW, M5 (for 200mm)
SW05
4
SW, M6 (for 150mm)
SW06
4
21
PW, M4 (for 150mm)
PW04
4
22
Washer (ø5 x ø14) (for 200mm)
T7-2-20380
4
PW, M6 (A) (for 150mm)
PW06A
4
