5. Maintenance & Adjustments
5.2 Accumulator Box Feed Adjustment
The machine has already been preset at the factory for proper feed, but if necessary, it can be changed
by the user. To adjust, loosen nut A and turn nut C upwards to increase the tension of spring B. After
making adjustments, be sure to re-tighten nut A.
EXCESSIVE PRESSURE COULD LEAD TO FEEDING PROBLEMS AS THE
STRAP CAN BE SCRAPED BY THE ROLLERS AND CAUSE DEFORMITIES
IN THE STRAPPING MATERIAL
