8. Parts List & Illustrations
8.4 Assistant Roller Assembly (continued)
Description
Part Number
Qty
Assistant Roller Assembly (for 5-6mm)
M7-1-320001
1
Assistant Roller Assembly (for 9mm)
M7-1-320011
1
1
Assistant Roller Bracket (for 5-6mm)
M7-1-321100
1
Assistant Roller Bracket
(Stainless Steel) (for 5-6mm)
M7-1-321100EN
1
Assistant Roller Bracket (for 9mm)
M7-1-321110
1
Assistant Roller Bracket
(Stainless Steel) (for 9mm)
M7-1-321110EN
1
2
Shaft
M7-1-321200
2
3
Assistant Roller Base
M7-1-321300
1
4
Assistant Roller (for 5-6mm)
M7-1-321400
1
Assistant Roller (for 9mm)
M7-1-321410
1
5
SQ8 Sensor Base
M7-1-321501
1
6
Spacer
M7-1-321600
1
9
Proximity Switch (X20)(SQ8)
M7-6-301100
1
11
Bearing, 686ZZ
BR686ZZ
2
13
HBS,M2.5x12 (N)
HBS02.512N
1
14
HBS, M5x12 (N)
HBS0512N
4
16
HBS, M4x25 (N)
HBS0425N
2
17
HBS, M6x20 (N)
HBS0620N
1
19
SW, M2.5
SW02.5
1
20
SW, M4
SW04
2
21
SW, M5
SW05
4
26
PW, M5
PW05
2
30
HN, M2.5
HN02.5
1
