Eagle 710 - 8. Parts List & Illustrations; 8.4 Auto Strap Feeding Group (continued)

- 135 -
8. Parts List & Illustrations
8.4 Auto Strap Feeding Group (continued)
Description
Part Number
Qty
Auto Strap Feeding Group
(for 5-6mm, 550W~1050W)
M7-3-200001
1
Auto Strap Feeding Group
(for 9mm, 550W~1050W)
M7-3-200011
1
Auto Strap Feeding Group
(for 5-6mm, 1250W/1650W)
M7-3-200032
1
Auto Strap Feeding Group
(for 9mm, 1250W/1650W)
M7-3-200042
1
1
Guide Block (for 5-6mm)
M7-3-201100
1
Guide Block (for 9mm)
M7-3-201110
1
2
Upper Strap Guide (for 5-6mm)
M7-3-201200
1
Upper Strap Guide (for 9mm)
M7-3-201210
1
3
Lower Strap Guide (for 5-6mm)
M7-3-201300
1
Lower Strap Guide (for 9mm)
M7-3-201310
1
4
Strap Guide Cover (for 550W~1050W)
M7-3-201400
1
Strap Guide Cover
(for 1250W/1650W)
M7-3-201420
1
5
Lever
M7-3-201500
1
6
Inlet Guide (for 5-6mm)
M7-3-201601
1
Inlet Guide (for 9mm)
M7-3-201611
1
7
Cover
M7-3-201700
1
9
Inlet Strap Guide Center Upper
(for 5-6mm, 1250W/1650W)
M7-3-201901
1
Inlet Strap Guide Center Upper
(for 9mm, 1250W/1650W)
M7-3-201911
1
10
Inlet Strap Guide Center Lower
(for 5-6mm, 1250W/1650W)
M7-3-202001
1
Inlet Strap Guide Center Lower
(for 9mm, 1250W/1650W)
M7-3-202011
1
11
Roller Assembly
M7-3-210001
1
12
Movable Strap Guide Ass’y (5-6mm)
M7-3-220000
1
Movable Strap Guide Ass’y (9mm)
M7-3-220010
1
13
M4 Motor Ass’y (for 5-6mm)
M7-3-230000
1
M4 Motor Ass’y (for 9mm)
M7-3-230010
1
14
Assistant Roller Shaft Ass’y (5-6mm)
T7-3-20080
1
Assistant Roller Shaft Ass’y (9mm)
T7-3-20081
1
17
Spring Hook
M7-1-331500
1
18
Motor (M5)
T6-1-61211
1
20
Motor Cover
T6-8-10410
1
21
Spring
T7-1-70280
1
22
Grommet
T5-4-10580
1
