Eagle 710 - 8. Parts List & Illustrations; 8.4 Bandway Group (continued)

- 104 -
8. Parts List & Illustrations
8.4 Bandway Group (continued)
Description
Part Number
Qty
Bandway Group (for 5-6mm)
M7-2-200002
1
Bandway Group (Stainless) (for 5-6mm)
M7-2-200002S
1
Bandway Group (for 9mm)
M7-2-200012
1
Bandway Group (Stainless) (for 9mm)
M7-2-200012S
1
3
Cover (L)
M7-2-201300
1
Cover (L) (Stainless)
M7-2-201300S
1
4
Adjusting Plate
M7-2-201400
1
Adjusting Plate (Stainless)
M7-2-201400EN
1
5
Cover (R)
M7-2-201500
1
Cover (R) (Stainless)
M7-2-201500S
1
6
Plate
M7-2-201710
1
7
Plate (for 1250W/1650W)
M7-2-201720
1
8
Bumper Screw (for 850W~1650W)
M7-2-201801
4~12
11
Strap Track Frame Ass’y (for 5-6mm)
M7-2-210002
1
Strap Track Frame Ass’y (Stainless)
(for 5-6mm)
M7-2-210002S
1
Strap Track Frame Ass’y (for 9mm)
M7-2-210012
1
Strap Track Frame Ass’y (Stainless)
(for 9mm)
M7-2-210012S
1
17
Pin (for 550W~1050W)
T7-2-10210
4
Pin (for 1250W/1650W)
T7-2-10210
5
Pin (Stainless) (for 550W~1050W)
T7-2-10210S
4
Pin (Stainless) (for 1250W/1650W)
T7-2-10210S
5
18
Tube
M7-2-201900
4
21
FMS, M4x10 (N)
FMS0410N
4
FMS, M4x10 (Stainless)
FMS0410S
4
24
HBS, M4x8 (N)
HBS0408N
2
HBS, M4x8 (Stainless)
HBS0408S
2
25
HBS, M6x16 (N)
HBS0616N
8
27
HBS, M6x12 (N) (for 1250W/1650W)
HBS0612N
1
28
THS, M6x16 (N)
THS0616N
4
THS, M6x16 (Stainless)
THS0616S
4
31
NTE, M3 (for 550W~1050W)
NTE03
8
NTE, M3 (for 1250W/1650W)
NTE03
10
34
SW, M4
SW04
2
SW, M4 (Stainless)
SW04S
2
35
SW, M6 (for 550W/650W)
SW06
12
SW, M6 (for 850W~1650W)
SW06
16~25
36
SW, M6 (Stainless)
SW06S
4
39
PW, M6 (A)
PW06A
6
40
PW, M6 (A) (Stainless)
PW06AS
2
