Eagle 710 - 8. Parts List & Illustrations; 8.4 Heater Arm Assembly (continued)

- 56 -
8. Parts List & Illustrations
8.4 Heater Arm Assembly (continued)
Description
Part Number
Qty
1
Heater Crank
M7-1-141100
1
2
Heater Shaft
M7-1-141200
1
Heater Shaft (Stainless Steel/Optional)
M7-1-14200S
1
3
Heater Bracket
M7-1-141300
1
Heater Bracket (Stainless Steel/Option)
M7-1-141300S
1
4
Terminal Bracket
M7-1-141400
1
5
Isolator
M7-1-141500
1
7
Washer
WA-030501
1
9
Heater Set
M7-1-140101
1
11
Spring Hook
TA-073
1
12
Spring
TB-115
1
13
Heater Terminal
T5-1-12451
1
16
Heater-Insulation
T7-1-12412
3
21
Bearing, 636ZZ
BR636ZZ
1
24
Metal Bushing, 1515
MB1515
2
31
HBS, M4x12 (N)
HBS0412N
2
32
HBS, M5x16 (N)
HBS0516N
2
34
HBS, M5x30 (N)
HBS0530N
1
35
HBS, M6x20 (N)
HBS0620N
1
36
HBS, M5x40 (H)(N)
HBS0540HN
1
38
PMS, M3x10
PMS0310
2
41
HN, M4 (SUS)
HN04S
2
42
HN, M5
HN05
4
47
SW, M5
SW05
4
48
SW, M6
SW06
1
51
PW, M4
PW04
2
52
PW, M5
PW05
2
53
PW, M6 (A)
PW06A
1
54
PW, M6 (C)
PW06C
1
55
PW, M6 (C)(SUS)
PW06CS
1
