8. Parts List & Illustrations
8.4 Slide Table Frame Assembly (continued)
Description
Part Number
Qty
Slide Table Frame Ass’y (for 5-6mm)
M7-1-130002
1
Slide Table Frame Ass’y (for 9mm)
M7-1-130030
1
1
Slide Table Frame
M7-1-131102
1
2
Shaft
M7-1-131200
1
3
Switch Lever
M7-1-131301
1
4
Sensor Plate
M7-1-131400
1
5
Spring Base
M7-1-131500
1
6
Slide Table
M7-1-131600
1
Slide Table (Stainless Steel/Optional)
M7-1-131600S
1
7
Spring Hook
M7-1-131700
1
10
Spring (for 5-6mm)
MSP-C-0607700
1
Spring (for 9mm)
MSP-C-0808100
1
11
Spring
T7-1-10140
1
12
Washer (SUS)
MWA-A-0610020S
2
16
Bearing, 6202ZZ
BR6202ZZ
1
18
Snap Ring, E-4
ER04
1
19
Metal Bushing, 0608
MB0608
2
20
Metal Bushing, 1515
MB1515
2
24
HB, M6x12
HB0612
1
27
HBS, M3x6 (N)
HBS0306N
2
28
HBS, M5x12 (N)
HBS0512N
2
29
HBS, M6x16 (N)
HBS0616N
4
36
HN, M6
HN06
1
41
SW, M3
SW03
2
42
SW, M5
SW05
2
43
SW, M6
SW06
6
46
PW, M6 (C)
PW06C
1
