Eagle 710 - 8. Parts List & Illustrations; 8.4 Strap Track Frame Assembly (continued)

- 111 -
8. Parts List & Illustrations
8.4 Strap Track Frame Assembly (continued)
Description
Part Number
Qty
12
Spring
T7-2-20172
4
Spring (Stainless)
T7-2-20172S
4
13
Bracket
T7-2-20180
4
14
Washer (for 550W~1050W)
T7-2-20380
4
Washer (for 1250W/1650W)
T7-2-20380
6
15
Spring (for 1250W/1650W)
T7-2-20171
2
Spring (Stainless) (for 1250W/1650W)
T7-2-20171S
2
19
Bearing, 608ZZ
BR608ZZ
4
20
Bearing, PB8 (for 550W~1050W)
BRPB8
4
Bearing, PB8 (for 1250W/1650W)
BRPB8
6
23
Metal Bushing, 0816
(for 550W~1050W)
MB0816
4
Metal Bushing, 0816
(for 1250W/1650W)
MB0816
6
26
HBL, M5x12
HBL0512
2
29
FMS, M4x20 (N)
FMS0420N
2
FMS, M4x20 (Stainless)
FMS0420S
2
30
FMS, M4x25
FMS0425
16~25
FMS, M4x25 (Stainless)
FMS0425S
16~25
33
HBS, M4x12 (N) (for 550W~1050W)
HBS0412N
7
HBS, M4x12 (N) (for 1250W/1650W)
HBS0412N
9
34
HBS, M6x12 (N)
HBS0612N
8
35
HBS, M5x40 (N)
HBS0540N
1
36
HBS, M5x12 (N)
HBS0512N
2
38
TMS, M4x8 (N) (for 550W~1050W)
TMS0408N
4
TMS, M4x8 (N) (for 1250W/1650W)
TMS0408N
6
41
Stop Ring, S-8
SR08
4
43
HN, M4
HN04
18~27
44
HN, M5
HN05
2
46
SW, M4
SW04
23~33
47
SW, M5
SW05
4
SW, M5
SW05
5
48
SW, M6
SW06
8
51
PW, M4
PW04
23~33
52
PW, M6 (C)
PW06C
8
53
PW, M5
PW05
2
PW, M5
PW05
3
