Eagle 710 - 8.3 Gear Box & Cam Assembly (continued)

- 47 -
8.3 Gear Box & Cam Assembly (continued)
Description
Part Number
Qty
Gear Box & Cam Assembly (for 5-6mm)
M7-1-110002
1
Gear Box & Cam Assembly (for 9mm)
M7-1-110020
1
1
Retracting Cam
M7-1-111100
1
2
Tension Cam
M7-1-111200
1
3
Heater Cam
M7-1-111300
1
4
Front Bar Cam
M7-1-111400
1
5
Press Bar Cam
M7-1-111500
1
6
Rear Bar Cam (for 5-6mm)
M7-1-111601
1
Rear Bar Cam (for 9mm)
M7-1-111610
1
7
Slide Table Cam
M7-1-111701
1
9
Support
M7-1-111900
2
10
Cam Shaft
M7-1-112001
1
11
Position Cam
M7-1-112101
1
12
Arch Cam
M7-1-112201
1
16
Gear Box
M7-1-110100
1
21
Washer
TB-223
2
22
Handle
T7-1-11240
1
26
Bearing, 6003ZZ
BR6003ZZ
2
28
Spacer
MCO-A-1700800
1
30
Key, 2x2x10
KYA020210
1
31
Key, 5x5x30
KYA050530
1
33
Key, 5x5x101
KYA0505101
2
36
Cap, M6
CAP06
1
39
HBS, M6x16 (N)
HBS0616N
1
40
HBS, M6x25 (N)
HBS0625N
4
42
HSS, M5x5 (G)(N)
HSS0505GN
1
43
HSS, M6x6 (G)(N)
GSS0606GN
9
46
SW, M6
SW06
6
51
HB, M6x16 (N)
HB0616N
1
