3. Machine Setup & Installation
3.3 Installation (Continued)
3. Adjust the table height by repositioning the screws underneath the machine frame (refer to
below drawing). After adjustments, be sure to tighten all the fixing screws.
BE SURE TO REMOVE THE WIRE FOR THE PROXIMITY SWITCH
UNDER THE LEFT SIDE OF THE MACHINE TO AVOID DAMAGE WHILE
ADJUSTING TABLE HEIGHT
4. After positioning the machine, be sure to lock the two front casters.
5. When moving the machine, be sure to un-lock the casters. Re-lock the casters after
repositioning the machine.
6. Do not move the machine unless it is necessary. Before movement, be sure to turn off and
disconnect power from the machine.
7. Minimum requirements for electrical supply
a. The electrical supply cord for the machine must have a minimum cross-section of at least
1.0 mm
2
(16 AWG).
b. The maximum power line fuse must not exceed 16 Amp.
