Eagle 710 - 8. Parts List & Illustrations; 8.4 Reel Control Group (continued)

- 164 -
8. Parts List & Illustrations
8.4 Reel Control Group (continued)
Description
Part Number
Qty
Reel Control Group (for 200mm)
M7-4-100001
1
Reel Control Group (for 150mm)
M7-4-100011
1
1
Inner Flange (for 200mm)
M7-4-101101
1
Inner Flange (for 150mm)
T7-4-10112
1
2
Shaft
M7-4-101200
1
3
Base (L)
M7-4-101301
1
4
Base (R)
M7-4-101401
1
5
Collar
M7-4-101500
2
7
Label
LA-30240
1
8
Collar
M7-1-101600
1
11
Outer Flange Assembly (for 200mm)
M7-4-110001
1
Outer Flange Assembly (for 150mm)
M7-4-110010
1
12
Reel Crank Assembly (for 200mm)
M7-4-120001
1
Reel Crank Assembly (for 150mm)
M7-4-120011
1
16
HBS, M6x10 (N)
HBS0610N
4
17
HBS, M6x12 (N)
HBS0612N
2
21
THS, M5x8 (N)
THS0508N
2
22
THS, M6x12 (N)
THS0612N
2
26
SW, M5
SW05
2
27
SW, M6
SW06
8
31
PW, M5
PW05
2
32
PW, M6 (A)
PW06A
8
36
HSS, M5x5 (G)(N)
HSS0505GN
2
41
Metal Bushing, 1510
MB1510
1
42
Metal Bushing, 1515
MB1515
1
