Eagle 710 - 8. Parts List & Illustrations; 8.2 Cam Group (continued)

- 43 -
8. Parts List & Illustrations
8.2 Cam Group (continued)
Description
Part Number
Qty
-
Cam Group (for 5-6mm)
M7-1-100023
1
-
Cam Group (for 9mm)
M7-1-100041
1
1
Strapping Head Frame
M7-1-101100
1
2
Guide
M7-1-101200
2
3
Ejector Plate (L)
M7-1-101300
1
4
Ejector Plate (R)
M7-1-101400
1
5
Shaft
M7-1-101500
1
6
Collar
M7-1-101600
1
7
Cover
M7-1-101700
1
8
Sensor Base
M7-1-101800
1
9
Coupling
M7-1-101900
1
10
Spring
M7-1-102000
1
21
Gear Box & Cam Assembly (for 5-6mm)
M7-1-110002
1
-
Gear Box & Cam Assembly (for 9mm)
M7-1-110020
1
22
M1 Motor Assembly
M7-1-120000
1
23
Slide Table Frame Ass’y (for 5-6mm)
M7-1-130002
1
-
Slide Table Frame Ass’y (for 9mm)
M7-1-130030
1
24
Heater Arm Assembly
M7-1-140000
1
25
Exhaust Fan Assembly
M7-1-150000
1
26
Block Assembly
T7-1-16000
1
29
Proximity Sensor
MV-6-20220
3
30
Washer
H42-1227
3
31
Spring Hook
TA-089
1
32
Bumper
T7-1-10330
4
33
Bumper Bracket
M7-1-102500
2
34
Return Spring
T7-1-64130
1
36
Label
LA-40002
1
38
Metal Bushing, 1515
MB1515
1
41
Spring Pin, 5x14
SP0514
2
43
HBS, M3x8 (N)
HBS0308N
4
44
HBS, M5x16 (N)
HBS0516N
4
45
HBS, M5x25 (H)(N)
HBS0525HN
2
46
HBS, M6x40 (H)(N)
HBS0640HN
3
47
HBS, M6x45 (H)(N)
HBS0645HN
4
48
HBS, M6x20 (N)
HBS0620N
2
49
HBS, M8x40 (H)(N)
HBS0840HN
2
50
HBS, M8x65 (H)(N)
HBS0865HN
2
51
HBS, M5x6 (G)(N)
HSS0506GN
2
52
HBS, M6x10 (G)(N)
HSS0610GN
2
55
HBS, HN, M8
HN08
4
58
THS, M5x8 (N)
THS0508N
2
