Eagle 710 - 8. Parts List & Illustrations; 8.4 Feed Group (continued)

- 75 -
8. Parts List & Illustrations
8.4 Feed Group (continued)
Description
Part Number
Qty
Feed Group (for 5-6mm)
M7-1-300002
1
Feed Group (for 9mm)
M7-1-300012
1
3
Bearing Housing
M7-1-301300
1
4
Guide Wheel (for 5-6mm)
M7-1-301400
1
Guide Wheel (for 9mm)
M7-1-301410
1
5
Spacer (for 5-6mm)
M7-1-301500
1
Spacer (for 9mm)
M7-1-301510
1
11
Feeding Motor (M2) Set
M7-1-300100
1
Upper Guide Assembly (for 5-6mm)
M7-1-310001
1
Upper Guide Assembly (Stainless Steel)
(for 5-6mm)
M7-1-310001S
1
Upper Guide Assembly (for 9mm)
M7-1-310011
1
Upper Guide Assembly (Stainless Steel)
(for 9mm)
M7-1-310011S
1
12
Assistant Roller Assembly (for 5-6mm)
M7-1-320001
1
Assistant Roller Assembly (for 9mm)
M7-1-320011
1
13
Feeding Arm Assembly
M7-1-330000
1
14
Retracting Arm Assembly
M7-1-340000
1
18
Bearing, 6002ZZ
BR6002ZZ
1
22
Key, 4x4x15
KYA040415
1
25
HBS, M4x12 (N)
HBS0412N
2
26
HBS, M5x12 (N)
HBS0512N
2
27
HBS, M5x16 (N)
HBS0516N
6
28
HBS, M6x12 (N)
HBS0612N
3
31
TMS, M5x8 (N)
TMS0508N
1
34
SW, M4
SW04
2
35
SW, M5
SW05
8
36
SW, M6
SW06
3
38
PW, M4
PW04
2
39
PW, M5
PW05
2
40
PW, M6 (A)
PW06A
1
41
PW, M6 (C)
PW06C
2
