Eaton MMX34AA9D0 Series User Manual

04/10 MN04020001Z-EN
List of parameters
181
P3.34 1421 / rw DI4 logic
(control signal terminal 14)
Like P3.31 82 0
P3.35
1422 / rw DI5 logic
(control signal terminal 15)
Like P3.31 82 0
P3.36
1423 / rw DI6 logic
(control signal terminal 16)
Like P3.31 82 0
P3.37
1480 / rw Hand mode like P3.2 82 0
Analog output
P4.1
307 / rw AO signal (Analog Output) 0 = Deactivated
1 = Output frequency
f-Out = 0 – f
max
(P6.4)
2 = Output current
I2 = 0 – I
N Motor
(P7.1)
3 = Torque M
N
= 0 – 100 % (calculated
value)
4 = PID controller, output
(0 - 100 %)
83 1
P4.2
310 / rw AO, minimum value 0 = 0 V
1 = 2 V (live-zero)
83 1
P4.3
1456 / rw AO, gain 0.00 - 200.00 % 83 100.00
P4.4
1477 / rw AO, filter time 0.00 - 10.00 s 83 0.0
Digital output
P5.1 313 / rw RO1 Signal
(Relay 1 Output)
0 = Deactivated
1 = READY, ready for operation
2 = RUN, enable (FWD, REV)
3 = FAULT, error message
4 = Error message (inverted)
5 = ALARM, warning
6 = REV, anticlockwise rotating field
7 = Output frequency = frequency
setpoint
8 = Motor controller active
9 = Zero frequency
10 = Frequency monitoring 1
11 = Frequency monitoring 2
12 = PID control
13 = Overtemperature message
14 = Overcurrent control active
15 = Overvoltage control active
16 = PLC Sequence control active
17 = PLC Sequence control, single step
completed
18 = PLC Sequence control, program
cycle completed
19 = PLC Sequence control, pause
20 = Counter, value 1 reached
21 = Counter, value 2 reached
22 = RUN message active
23 = Setpoint error (live-zero)
24 = LOG function fulfilled
25 = PID controller, actual value
monitoring
26 = External brake actuated
27 = Current monitoring
28 = Fieldbus, remote output
84 2
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
