04/10 MN04020001Z-EN
List of parameters
183
P6.8 506 - rw Stop function 0 = Fee coasting
1 = Ramp, deceleration
90 0
P6.9
500 - rw S ramp,
time-based S-form
0.00 = Linear
0.1 - 10.0 s (S-shaped)
90 0.0
P6.10
717 - rw REAF, Wait time before an
automatic restart
0.10 - 10.00 s 91 0.50
P6.11
718 - rw REAF, Test time before an
automatic restart
0.00 - 60.00 s 91 30.00
P6.12
719 - rw REAF, Start function with
automatic restart
0 = Ramp
1 = Flying restart circuit
2 = Set as in P6.7
91 0
P6.13
731 - rw REAF, automatic restart
after an error message
0 = deactivated
1 = activated
91 0
P6.14
1600 - rw Stop on rotation direction
change (KEYPAD)
0 = Deactivated
1 = Activated
91 1
P6.15
184 - rw Setpoint input (REF) -P6.4 - 0.00 - +P6.3 Hz 92 0.00
P6.16
1474 - rw STOP button 0 = Deactivated
1 = Activated
92 1
P6.17
1427 - rw Control place 2 1 = Control signal terminals (I/0)
2 = Control unit (KEYPAD)
3 = Field bus (BUS)
92 3
P6.18
1428 - rw Setpoint Source 2 0 = Fixed frequency (FF0)
1 = Operating unit (REF)
2 = Fieldbus (BUS)
3 = AI1 (analog setpoint 1)
4 = AI2 (analog setpoint 2)
5 = Motor potentiometer
92 2
P6.19 502 - rw Second acceleration time
(acc2)
0.1 - 3000 s 92 10.0
P6.20
503 - rw Second deceleration time
(dec2)
0.1 - 3000 s 92 10.0
P6.21
526 - rw Transition frequency
(acc1 - acc2)
0.00 - P6.4 Hz 92 0.00
P6.22
1334 - rw Transition frequency
(dec1 - dec2)
0.00 - P6.4 Hz 92 0.00
P6.23
1429 - rw REV blocked 0 = Deactivated
1 = Activated
92 0
P6.24
509 - rw Frequency jump 1, lower
value
0.00 - P6.4 Hz 93 0.00
P6.25
510 - rw Frequency jump 1, upper
value
0.00 - P6.4 Hz 93 0.00
P6.26
511 - rw Frequency jump 2, lower
value
0.00 - P6.4 Hz 93 0.00
P6.27
731 - rw Frequency jump 2, upper
value
0.00 - P6.4 Hz 93 0.00
P6.28
513 - rw Frequency jump 3, lower
value
0.00 - P6.4 Hz 93 0.00
P6.29
514 - rw Frequency jump 3, upper
value
0.00 - P6.4 Hz 93 0.00
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
