Appendix
04/10 MN04020001Z-EN
184
P6.30 759 - rw REAF, number of automatic
restarts
1-10 93 3
P6.31
1481 - rw Manual mode, control level 1 = Control signal terminals (I/0)
2 = Control unit (KEYPAD)
3 = Field bus (BUS)
93 1
P6.32
1482 - rw Manual mode,
setpoint source
0 = Fixed frequency (FF0)
1 = Operating unit (REF)
2 = Fieldbus (BUS)
3 = AI1 (analog setpoint 1)
4 = AI2 (analog setpoint 2)
5 = Motor potentiometer
93 3
P6.33 1483 - rw Manual mode,
KEYPAD blocked
0 = Deactivated
1 = Activated
93 1
Motor
P7.1 113 - rw Motor, rated operational
current
0.2 x I
e
-2xI
e
(h Motor rating plate)
94 I
e
P7.2 107 - rw Current limitation 0.2 x I
e
-2xI
e
94 1.5 x I
e
P7.3 112 - rw Motor, rated speed 300 - 20000 min
-1
(h Motor rating plate)
94 1440
1720
P7.4
120 - rw Motor, power factor
(cos v)
0.30 - 1.00
(h Motor rating plate)
94 0.85
P7.5
110 - rw Motor, rated operating
voltage
180 - 500 V
(h Motor rating plate)
94 230
400
P7.6
111 - rw Motor, rated frequency 30 - 320 Hz
(
h Motor rating plate)
94 50.00
60.00
Protective functions
P8.1
700 - rw Setpoint error (live-zero) 0 = Deactivated
1 = Warning
2 = Error, stop according to P6.8
95 1
P8.2
727 - rw Undervoltage error Like P8.1 95 2
P8.3
703 - rw Earth-fault protection Like P8.1 95 2
P8.4
709 - rw Blocking protection
mechanism
Like P8.1 96 1
P8.5
713 - rw Underload protection Like P8.1 96 0
P8.6
704 - rw Motor, temperature
protection
Like P8.1 96 2
P8.7
705 - rw Motor, ambient
temperature
-20 - +100 °C 96 40
P8.8
706 - rw Motor, cooling factor at
zero frequency
0.0 - 150 % 96 40
P8.9
707 - rw Motor,
thermal time constant
1 - 200 min 96 45
P8.10
1430 - rw Setpoint error (live-zero),
reaction time
0.0 - 10.0 s 98 0.5
P8.11
1473 - rw (Reserve) Like P8.1 98 0
P8.12
714 - rw Underload protection
at cut-off frequency
10.0 - 150 % 98 50.0
60.0
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
