Eaton MMX34AA9D0 Series User Manual

04/10 MN04020001Z-EN
List of parameters
187
P11.5 605 - rw U/f characteristic curve,
mean
voltage value
0.00 - P11.3 % 113 100.00
P11.6
606 - rw Output voltage at zero
frequency
0.00 - 40.00 % 113 0.00
P11.7
109 - rw Torque increase 0 = Deactivated
1=active
113 0
P11.8
600 - rw Control mode 0 = Frequency control (U/f)
1 = Speed control with
slip compensation
113 0
P11.9
601 - rw Pulse frequency 1.5 - 16.0 kHz 115 6.0
P11.10
522 - rw Stabilize pulse frequency,
(sinusoidal filter)
0 = Deactivated
1=activated^
115 0
Braking
P12.1 507 - rw DC braking, current 0.2 x I
e
-2xI
e
116 I
e
P12.2 516 - rw DC braking, braking time at
start
0.00 - 600.00 s 116 0.00
P12.3
515 - rw DC braking,
start frequency during
delay ramp
0.00 - 10.00 Hz 117 1.50
P12.4
508 - rw DC braking, braking time in
case of STOP
0.00 - 600.00 s 118 0.00
P12.5
504 - rw Brake chopper (only active and visible with braking
transistor installed)
0 = Deactivated
1 = Automatic activation in operation
(RUN)
2 = Automatic activation in operation
(RUN) and upon stop (STOP)
119 0
P12.6
1447 - rw Brake chopper,
switching threshold
(only active and visible with braking
transistor installed)
0 - 870 V
119 0
P12.7
1448 - rw Open external brake,
deceleration time
0.00 - 320.00 s 120 0.20
P12.8
1449 - rw Open external brake,
frequency limit value
0.00 - P6.4 Hz 120 1.50
P12.9
1450 - rw Close external brake,
frequency limit value
0.00 - P6.4 Hz 120 1.00
P12.10
1451 - rw Close external brake,
frequency limit value on
reversing (REV)
0.00 - P6.4 Hz 120 1.50
P12.11
1452 - rw Open external brake,
current limit value
0.00 – P7.2 A 120 0.00
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
