Eaton MMX34AA9D0 Series User Manual

Appendix
04/10 MN04020001Z-EN
186
P9.19 1476 / rw PID controller,
scale actual value display
0.1 - 32.7 102 1.0
P9.20
1478 / rw PID controller, output
signal limitation
0.00 - 100.0 % 102 100.0
Fixed frequencies
P10.1 124 / rw Fixed frequency FF0 0.00 - P6.4 Hz 105 5.00
6.00
P10.2
105 / rw Fixed frequency FF1 0.00 - P6.4 Hz 105 10.00
12.00
P10.3
106 / rw Fixed frequency FF2 0.00 - P6.4 Hz 105 15.00
18.00
P10.4
126 / rw Fixed frequency FF3 0.00 - P6.4 Hz 105 20.00
24.00
P10.5
127 / rw Fixed frequency FF4 0.00 - P6.4 Hz 105 25.00
30.00
P10.6
128 / rw Fixed frequency FF5 0.00 - P6.4 Hz 105 30.00
36.00
P10.7
129 / rw Fixed frequency FF6 0.00 - P6.4 Hz 105 40.00
48.00
P10.8
130 / rw Fixed frequency FF7 0.00 - P6.4 Hz 105 50.00
60.00
P10.9
1436 / rw PLC Sequence control 0 = Deactivated
1 = Program cycle, execute once
2 = Execute program cycle continuously
3 = Execute program cycle in steps
4 = Execute program cycle continuously
in steps
106 0
P10.10
1437 / rw PLC Sequence control,
program (FWD/REV)
0 - 255 106 0
P10.11
1438 / rw Set time for FF0 0 - 10000 s 107 0
P10.12
1439 / rw Set time for FF1 0 - 10000 s 107 0
P10.13
1440 / rw Set time for FF2 0 - 10000 s 107 0
P10.14
1441 / rw Set time for FF3 0 - 10000 s 107 0
P10.15
1442 / rw Set time for FF4 0 - 10000 s 107 0
P10.16
1443 / rw Set time for FF5 0 - 10000 s 107 0
P10.17
1444 / rw Set time for FF6 0 - 10000 s 107 0
P10.18
1445 / rw Set time for FF7 0 - 10000 s 107 0
U/f-characteristic curve
P11.1
108 - rw U/f characteristic
curve
0 = Linear
1 = Quadratic
2 = Configurable
111 0
P11.2
602 - rw Cut-off frequency 30.00 - 320.00 Hz 112 50.00
60.00
P11.3
603 - rw Output voltage 10.00 – 200.00 % of the motor
rated voltage (P6.5)
112 100.00
P11.4
604 - rw U/f characteristic curve,
mean frequency value
0.00 - P11.2 Hz 113 50.00
60.00
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
