Eaton MMX34AA9D0 Series User Manual

04/10 MN04020001Z-EN
List of parameters
191
User Set
S4.1
830 / rw Display contrast 0-15 129 7
S4.2
831 - rw Restore factory defaults
(FS)
0 = Factory setting or changed value
1 = Restores factory settings for all
parameters
129 0
S4.3
832 / ro Password 0000 - 9999 129 0000
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
h
Parameters marked with "M" (Monitor) are values
currently being measured, variables calculated from these
measured values, or status values from control signals.
The M parameters cannot be edited (only display values)
PNU ID Access right Designation Value range Page Display
format
Measu
red
values
ro/rw
Display values
M1.1 1
ro
Output frequency Hz 130 0.00
M1.2
25
ro
Frequency reference value Hz 130 0.00
M1.3
2
ro
Motor shaft speed rpm (calculated value, rpm) 130 0
M1.4
3
ro
Motor current A 130 0.00
M1.5
4
ro
Motor torque % (calculated value) 130 0.0
M1.6
5
ro
Motor power % (calculated value) 130 0.0
M1.7
6
ro
Motor voltage V 130 0.0
M1.8
7
ro
Intermediate DC voltage
circuit
V 130 0.0
M1.9
8
ro
Unit temperature °C 130 0
M1.10
9
ro
Motor temperature % (calculated value) 130 0
M1.11
13
ro
Analog input 1 % 130 0.0
M1.12
14
ro
Analog input 2 % 130 0.0
M1.13
26
ro
Analog output 1 % 130 0.0
M1.14
15
ro
Digital input 1 - 3 DI1, DI2, DI3 status 130 0
M1.15
16
ro
Digital input 4 - 6 DI4, DI5, DI6 status 130 0
M1.16
17
ro
Digital output RO1, RO2, DO status 130 1
M1.17
20
ro
PID setpoint % 131 0.0
M1.18
21
ro
PID feedback % 131 0.0
M1.19
22
ro
PID error value % 131 0.0
M1.20
23
ro
PID output % 131 0.0
M1.21
1480
ro
Counter, digital input - 131 0
