For more information visit: www.EatonElectrical.com
EZ800/EZD Control Commands
MN05013001E96
Table 43: Byte 4 – 8: Data 1 – 5
Winter/summer time, DST
Telegram structure
Byte Contents Value (hex)
4 Data 1 Hour (0 to 23) 00 – 17
5 Data 2 Minute (0 to 59) 00 – 3B
6 Data 3 Day (1 to 28; 29, 30, 31;
depending on month and
year)
01 – 1F
7 Data 4 Month (1 to 12)
01 – 0C
8 Data 5 Year (0 – 99,
corresponds to 2000 – 2099)
00 – 63
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command
Read 93 –
Write B3 –
Response
Read
successful
– C2
Write
successful
– C1
Command
rejected
– C0
2 Len
05 05
3 Index 01 01
4 – 8 Data 1 – 5
Read operation 00 J Table 44
For write
operation
J Table 44 00
