EZ204-DP
MN05013001E14
Device function description The EZ204-DP module allows the EZ and EZD series devices
to be connected to a PROFIBUS-DP communication network.
The following data can be transferred by selecting the
appropriate SDO/PDO:
EZ700/800, EZD-CP8..
• S1 to S8
Output data of the basic unit, RUN/STOP
(read, as viewed from PROFIBUS-DP master)
• R1 to R16
Input data of the basic unit, RUN/STOP
(write, as viewed from PROFIBUS-DP master)
• All function relay data
(read, as viewed from the PROFIBUS-DP master)
– Timing relays
– Counter relays
– Time switches
– Analog comparators
– Weekday, time, summer/winter time (DST)
• The setpoints of the function relays
(write, as viewed from PROFIBUS-DP master)
– Timing relays
– Counter relays
– Time switches
– Analog comparators
– Weekday, time, summer/winter time (DST)
