For more information visit: www.EatonElectrical.com
EZ800/EZD Control Commands
MN05013001E112
Reading RW.. inputs/SW.. outputs from EZ-LINK
This service allows you to read the local R and S data and the
data of the NET stations (1 – 8) transferred via EZ-LINK, again
from the relevant EZ800/EZD image.
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command: Read
91
Response:
Read successful C2
Command
rejected
C0
2Len
02 02
3Type
For RW: 07 For RW: 07
For SW: 09 For SW: 09
4 Index 00/01 – 08
1
00/01 – 08
1
5 Data 1 (Low Byte) 00 J Table 49
6 Data 2 (High Byte) 00 J Table 49
7 – 8 Data 3 – 4 00 00
1) 00 = Local input/output
01 – 08 = Address of network station (NET-ID 1 – 8)
