EZ800/EZD Control Commands
MN05013001E170
Pulse width modulation function blocks PW01 .. PW02
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94 J page 94
1Command:
Read 92 –
Write B2 –
Response:
Read successful – C2
Write successful – C1
Command
rejected
– C0
2Type 2B 2B
3 Instance 01 – 02 01 – 02
4 Index J Table 106 J Table 106
5 – 8 Data 1 – 4
Read operation 00 depending on
index,
J Table 107
Write operation
depending on
index,
J Table 107
00
