For more information visit: www.EatonElectrical.com 17MN05013001E
2Installation
The same principles apply as for EZ700, EZ800 and EZD
basic units with expansion devices.
Connecting EZ204-DP to the basic unit
Figure 3: Fitting + or removing + the EZ204-DP to the
basic unit
1
3
4
2
1
2 3 4
