Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 147
PID controllers DC01 .. DC32
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94 J page 94
1Command:
Read 92 –
Write B2 –
Response:
Read successful – C2
Write successful – C1
Command
rejected
– C0
2Type 27 27
3 Instance 01 – 20 01 – 20
4 Index J Table 81 J Table 81
5 – 8 Data 1 – 4
Read operation 00 depending on
index,
J Table 82, 83
Write operation
depending on
index,
J Table 82, 83
