For more information visit: www.EatonElectrical.com
EZ800/EZD Control Commands
MN05013001E154
7-day time switches HW01 .. HW32
Telegram structure
Table 89: Operand overview
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command: Read
92 –
Response:
Read successful – C2
Command
rejected
– C0
2Type
1C 1C
3Instance
01 – 20 01 – 20
4 Index J Table 89
5 – 8 Data 1 – 4 00 depending on
index,
J Table 90
Index
(hex)
Operand Read Write
00 Bit IO J Table 90 ×
01 Mode/Parameter – –
02 Parameters J Table 91 ×
Channel A
03 Channel B
04 Channel C
05 Channel D
