Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 155
Table 90: Index 0 – Bit IO
The data in the following table is shown in the Motorola format
although it is actually transferred in Intel format.
Table 91: Index 2 – 5, Parameter channels A – D
Bit 7 6 5 4 3 2 1 0
FB output Data 3 – – – – – – – Q
1
1) Status 1 if the switch-on condition is fulfilled.
Bit 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
Date 2 Date 1
ON
d4 d3 d2 d1 d0 h4 h3 h2 h1 h0 m5 m4 m3 m2 m1 m0
Weekday Hour Minute
Bit 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
Date 4 Date 3
OFF d4 d3 d2 d1 d0 h4 h3 h2 h1 h0 m5 m4 m3 m2 m1 m0
Weekday Hour Minute
m5 to m0: Minute (0 to 59)
h4 to h0: Hour (0 to 23)
d5 to d0: Weekday (0 = Sunday to 6 = Saturday)
