Control commands for EZ700
MN05013001E58
Markers: M1 – M16/N1 – N16
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 44
1Command: Write
8C –
Response:
Write successful – C1
Command
rejected
– C0
1
2 Len 01 01
3Type
2
With M marker 86 86
With N marker 87 87
4 Index
2
00 – 0F 00 – 0F
5 Data 1 (Low Byte)
3
00/01 00/01
6 – 8 Data 2 – 4 00 00
1) Possible causes J page 91
2) There are 16 M markers and 16 N markers. The markers are
addressed by Type and Index:
Use Type to select the M or N marker.
Use Index to select the marker number.
3) The marker is set if a value is written to the data byte that does
not equal zero. The marker is reset accordingly if the value 0
is written to data byte Data 1.
