Control commands for EZ700
MN05013001E54
Local inputs: I1 – I16
This command string enables you to read the local inputs of
the EZ700 basic unit. The relevant input word is stored in Intel
format.
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 44
1 Command: Read
88 –
Response:
Read successful – C2
Command
rejected
– C0
1)
2Len 02 02
3Type
84 84
4 Index 00 00
5 Data 1 (Low Byte) 00 J Table 13
6 Data 2 (High Byte) 00 J Table 13
7 – 8 Data 3 – 4 00 00
1) Possible causes J page 91
