Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 157
Year time switches HY01 .. HY32
Telegram structure
Table 92: Operand overview
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command: Read
92 –
Response:
Read successful – C2
Command
rejected
– C0
2Type
1D 1D
3Instance
01 – 20 01 – 20
4 Index J Table 92
5 – 8 Data 1 – 4 00 depending on
index,
J Table 93
Index
(hex)
Operand Read Write
00 Bit IO J Table 93 ×
01 Mode/Parameter – –
02 Parameters J Table 94 ×
Channel A
03 Channel B
04 Channel C
05 Channel D
