Read/write image data
For more information visit: www.EatonElectrical.comMN05013001E 99
Read/write image data
Overview
J
Please also observe the relevant description of possible
image data provided in the EZ800 manual, the EZD
manual, or in the EZSoft Help.
The latest editions of these manuals are available as PDF
files from the Internet at: www.EatonElectrical.com
. EZ800
manual search term: MN05013004E. EZD manual search
term: MN05013005E.
The information provided in Section “General notes on
working with image data” on Page 49 also applies to
EZ800/EZD.
Operands Meaning Read/write Command Page
IW0 Read local inputs IW0 Read 01 100
IW1 – IW8 Read inputs of the stations IW1 to IW8
Read 01 102
IA1 – IA4 Read local analog inputs IA1 to IA4
Read 02 103
ID1 – ID16 Read local diagnostics ID1 to ID16
Read 03 105
QW0,
QW1 – QW8
Read and write local QW0 outputs/outputs
of the stations QW1 to QW8
Read/write 04 107
QA1 Reading and writing local analog output
QA1
Read/write 05 109
P1 – P4 Reading local P buttons
Read 06 110
R1 – R16
S1 – S8
Reading RW.. inputs/SW.. outputs from
EZ-LINK
Read 07/09 112
RN1 – RN32
SN1 – SN32
Reading receive data network RN1 ..
RN32/send data network SN1 .. SN32
Read 08/0A 114
M... Reading and writing markers
Read/write 0B – 0E 116
