EZ204-DP
MN05013001E12
System overview The EZ204-DP slaves are integrated in a PROFIBUS-DP
system.
Figure 1: Integration of EZ204-DP in the DP network
Master area, PLC or PC
Slave area, e.g. EZ /EZD with DP interface
a
b
