Eaton PROFIBUS-DP EZ204-DP User Manual

For more information visit: www.EatonElectrical.com
EZ800/EZD Control Commands
MN05013001E140
Comparators CP01 .. CP32
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1Command:
Read 92 –
Write B2 –
Response:
Read successful – C2
Write successful – C1
Command
rejected
– C0
2Type 18 18
3 Instance 01 – 20 01 – 20
4 Index J Table 75 J Table 75
5 – 8 Data 1 – 4
Read operation 00 depending on
index,
J Table 76
Write operation
depending on
index,
J Table 76
00
