Control commands for EZ700
MN05013001E50
Overview
Operands Meaning Read/
write
Type Page
A1 – A16 Analog value comparators/threshold
comparators: A1 – A16
Read 8C 51
C1 – C16 Counters: C1 – C16 Read EE 52
D1 – D16 Text function blocks: D1 – D16 Read 94 53
I1 – I16 Local inputs: I1 – I16 Read 84 54
IA1 – IA4 Local analog inputs: IA1 – IA4 Read 8C 56
M1 – M16,
N1 – N16
Markers: M1 – M16/N1 – N16 Write 86/87 58
M1 – M16,
N1 – N16
Markers: M1 – M16/N1 – N16 Read 86/87 60
O1 – O4 Operating hours counters: O1 – O4 Read EF 62
P1 – P4 Local P buttons: P1 – P4 Read 8A 63
Q1 – Q8 Local outputs: Q1 – Q8 Read 85 65
R1 – R16/
S1 – S8
Inputs/outputs of EZ-LINK: R1 – R16/S1 – S8 Read 88/89 66
T1 – T16 Timing relays: T1 – T16 Read ED 68
Y1 – Y4 Year time switch: Y1 – Y8 Read 91 69
Z1 – Z3 Master reset: Z1 – Z3 Read 93 70
H1 – H4 7-day time switch:
Ö1 – Ö8 Read 90 71
